| PRINTING ROTRAY SCREEN |
| Post Date :2017-01-06 |
| Expire Date :2015-08-01 |
 View Basket |
| moq: 20pcs, technical parameter: 640,820,914,1018,1168,1206,1450,1620,1680mm, use for: textile printing, model: 14,17,23,25,30,40mesh，60H(60VH)，80H(80VH) |
| Detailed Trade Lead Description |
Note:specific specification can be produced according to customers requirements as well as can produce in line with customers extraordinary requirements.
|
Characteristic: Thick wall, good elasticity , big hole,smooth slide, no chips at all and strong permeability, the surface of? screen shows streamlind and dysetuff can flow easily,It doesn t need big pressure while printing, and covers the surface of cloth evenly, widely used in printing wallpaper,lining cloth and coating, wax printing,etc.
目數(shù)(Mesh )
|
厚度(μm)
|
開(kāi)孔率(%)
|
孔徑(μm)
|
14
|
215
|
40
|
1140
|
17
|
215
|
40
|
945
|
23
|
215
|
38
|
680
|
25
|
215
|
35
|
600
|
30
|
215
|
30
|
465
|
40
|
200
|
30
|
330
|
60H
|
145
|
20
|
188
|
60VH
|
145
|
20
|
188
|
80H
|
125
|
18
|
136
|
80VH
|
125
|
18
|
136
|
|
Notes:
1. All screen with "V" the hole order is 45 angle. Especially used in printing pane and line, geometrical figure, etc.
2. All screen with "H" means extra thickness.
3. All kinds of screen can be used for 5~7 times repeatedly.
4. All screens can be customized according to users requirements.
|
|
|
|
